CNC Vari Angle Adjustable Chamfer Head on Shank 40mm Cut Width 663.201.11

CNC Adjustable Chamfer Vari Angle Router Head

CMT Ref: 663.201.11

Suitable for manual/mechanical feed CNC router machines and stationary router machine

85mm diameter

40mm carbide tip height

92mm overall length

102mm diameter once set at 45°

Infinitely variable with positive stops every 7.5°

Swivelling range 45° up and 90° down.

Right hand rotation

20mm shank

Solid aluminium body

Ideal for jointing, rebating and chamfering

Spares:

790.395.12 (39.5 x 12 x 1.5mm) Reversible Knives  (4 cutting edges)

     You will find all spare parts for this Cutter in the reversible turn blade category of our shop

 Please do not hesitate to contact our very own CNC commisioning engineer inhouse, Jeremy Appleby for Free of Charge Technical assistance before purchase.

 Thanks for looking and we hope to see you as a repeat customer of the future.

 We also offer combined shipping so if you require Knives with these Blocks we will combine the delivery.

 Note all prices shown are including Vat and a full Vat invoice is sent with every order.

 Picture is for advert purposes
