CMT 170mm Diameter x 20-39mm Cut Height 2 Piece Adjustable Groover with 31.75mm Bore

CMT PART CODE - 694.022.31

The ideal tool for use on Spindle Moulders, Double End Tennoners and Shaper machines to create precision slots and grooves between 20 to 39mm in a wide range of materials. Suitable for all materials, but best on Solid Woods (Hardwood & Softwood) Chipboard, MDF, Composites, Plastic Materials and Laminates.

This versatile 170mm diameter Adjustable Groover set consists of two solid Aluminium cutter heads and a set of spacer shims. In addition, both of the heads come pre-fitted with Two cutting Tips and Two Spur Tips. These tips are the European standard sizes and can be turned four times to use each of their edges in order to achieve crisp, clean and precise edges.

Cutting Diameter = 170mm

Groove Width = 20-39mm

Internal Bore Size = 31.75mm

Maximum Groove/Rebate Depth = 54mm

4HWM Knives - 19.5X12X1.5

4HWM Knives - 14X14X2

Hard Aluminum Alloy Body

Manual Feed

Pins for the Automatic Positioning of the Knives

RPM Min 4400-7400 Max

Image is for illustration purposes and will be exactly as described.
